CWDM OADM (1 Channel Optical Add/Drop Multiplexer)
Name:

CWDM OADM (1 Channel Optical Add/Drop Multiplexer)
Class:
 DWDM / OADM
Type:
 CWDM OADM (2 Channel Optical Add/Drop Multiplexer)
Optical Add/Drop Multiplexer,1 Channel CWDM OADM Specification

fiberw - Company Profile-2010
features
applications
low insertion loss
wide pass band
high channel isolation
high stability and reliability
epoxy free on optical path
cwdm grid
cwdm  channel add/drop
metro/access networks
catv fiber optic system
performance specifications
parameter
mux
demux
wavelength (nm)
1471, 1491 or 1470, 1490 etc.
center wavelength accuracy (nm)
¡À 0.5
channel spacing (nm)
20
channel passband (@-0.5db bandwidth)(nm)
>13
insertion loss (db)
add/drop ch.
< 0.6
express ch.
< 0.6
add/drop channel ripple (db)
< 0.3
isolation (db)
adjacent
n/a
>30
non-adjacent
n/a
>40
insertion loss temperature sensitivity (db/¡ãc )
< 0.003
wavelength temperature shifting (nm/ ¡ãc )
< 0.002
polarization dependent loss (db)
< 0.10
polarization mode dispersion (ps)
< 0.1
directivity (db)
>50
return loss (db)
>45
power handling (mw)
300
specifications may change without notice
ordering information
cwdm
configuration
1st  channel
fiber type
fiber length
connector
    in/out

1=1 ch add/drop
2=2 ch add/drop
471=1471nm
491=1491nm
1=bare fiber
2=900um jacket
1=1 meter
2=2 meter
0=none
1=fc/apc
2=fc/pc
3=sc/apc
4=sc/pc
5=st
6=lc
